Application and feature:
Used to analyse and measure mass fractions of silicon, manganese, phosphor, nickel, chrome, copper, molybdenum, iron, titan, rare earth, magnesium as well as other elements in steel, aluminum alloy and iron alloy.
1.Microcomputer control, procedure operation, data processing, simple structure, convenient operation
2.Curve automatically regress, digital display, printing, directly read mass fraction
3.Adopt photoelectrical colorimetry, with rapid speed, accurate result, stable and reliable
4.Can design the combination of any three elements according to users’ requirements
Technical index:
1.Measuring range:
iron: 0.100-1.50％
Copper: 0.050-1.500％
Silicon: 0.10%-5.00%，5.00-14％
Manganese: 0.10%-2.0%，2.0-11％，11-17％
Magnesium: 0.01-0.2％，0.2-1.5％
Titanium: 0.05-1.00％
Phosphor: 0.01%-0.10%，0.10-0.7％
Rare earth: 0.010-0.100％
Chrome: 0.050-2.00％，2.00-6.00％，6.00-27％
Molybdenum: 0.100-0.500％，0.500-1.00％，1.00-4.00％
Nickel: 0.050-2.00％，2.00-6.00％，6.00-27％
2.Analysis time: 4min
3.Error of analysis: according with the standards of GB/T6987.2、4.6、7.9、12-2001, B/T223.49-94、59-87、12-91、26-89、23-94
